| BRAND | AC Motoren |
| Product | ACA 160 MA-2 B5 / PHE |
| Description | three-phase asynchronous motor |
| Internal code | IMP4473900 |
| Weight | 150 |
| Custom code | 85015230 |
| Technical specification | 106336 Motor power:11.0 kW/50 Hz 13.2 kW/60 Hz Number of motor poles: 4 Motor voltage: 3 x 400/ 690 V +- 10%, 50 Hz 3 x 460/ 795 V+- 10%, 60 Hz Motor speed: 2945 rpm /50 Hz 3534 rpm /60 Hz Motor rated current: 19.56/11.34 A (50 Hz) 20.46/ 11.84 A (60 Hz) Efficiency class: IE3 Efficiency: 91.2 - 91.2 - 89.4% at 100 - 75 - 50% load cos phi: 0.89 Degree of protection: IP 55 Insulation class: F Design: IM B5 flange version Shaft end: 42 x 110 mm Terminal box location: top Coolant temperature: -20 to +40 °C Installation height: < 1000 m and sea level Coloring: RAL 7030 stone grey Additional equipment PTC 150°C |
Discover the superior quality and performance of the AC Motoren ACA 160 MA-2 B5 / PHE with Impexron GMBH in Singapore . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ACA 160 MA-2 B5 / PHE is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ACA 160 MA-2 B5 / PHE :
At Impexron GMBH , we offer the ACA 160 MA-2 B5 / PHE at competitive prices and with the fastest delivery times across Singapore . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the ACA 160 MA-2 B5 / PHE ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply AC Motoren products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ACA 160 MA-2 B5 / PHE by AC Motoren in Singapore?
You can purchase ACA 160 MA-2 B5 / PHE by AC Motoren from Impexron GMBH. We serve customers across Singapore, offering competitive prices and reliable service.
What is the price of the ACA 160 MA-2 B5 / PHE?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of AC Motoren in Singapore?
While we are not the official distributor or seller of AC Motoren in Singapore, we source our products from reliable channels and offer you original AC Motoren equipment at competitive prices.
How can I access ACA 160 MA-2 B5 / PHE catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ACA 160 MA-2 B5 / PHE on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ACA 160 MA-2 B5 / PHE?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
